Electrical Circuit - MCQs Part II

Posted by Unknown at 7:14 AM
Hits:
Electrical Circuit - MCQS Part II

Multiple Choice Questions Topic Outline

  • MCQs in AC-DC circuits
  • MCQs in Resistors
  • MCQs in Inductors
  • MCQs in Capacitors

The Six-Parts Series

Following is the list of multiple choice questions in this brand new series:

Electrical circuits MCQs
PART 1: MCQs from Number 1 – 50                        Answer key: PART I
PART  2: MCQs from Number 51 – 100                   Answer key: PART II
PART 3: MCQs from Number 101 – 150                  Answer key: PART III
PART 4: MCQs from Number 151 – 200                  Answer key: PART IV
PART 5: MCQs from Number 201 – 250                  Answer key: PART V
PART 6: MCQs from Number 251 – 300                  Answer key: PART VI

Start with Part II of the MCQs Series

51. Effects of capacitance

  • A. It opposes any change in the amount of voltage
  • B. Voltage is lagged behind the current by a quarter cycle
  • C. Electric energy is stored in the capacitor in the form of electrostatic field
  • D. All of the above

52. Points to be considered in choosing a capacitor

  • A. Working voltage
  • B. Type of dielectric
  • C. Capacitance
  • D. All of the above

53. Permeability is otherwise known as

  • A. Magnetic conductivity
  • B. Magnetic susceptibility
  • C. Electric conductivity
  • D. Electric susceptibility

54. The impedance in the study of electronics is represented by resistance and

  • A. Inductance
  • B. Capacitance
  • C. Inductance and capacitance
  • D. Reactance

55. Loop currents should be assumed to flow in which direction

  • A. Straight
  • B. Clockwise
  • C. Counter-clockwise
  • D. Either B or C arbitrarily selected

56. What determines the direction of induced emf in a conductor or coil?

  • A. Cork screw rule
  • B. Fleming’s left hand rule
  • C. Ampere’s circuital law
  • D. Fleming’s right hand rule

57. The reason why electrical appliances are connected in parallel.

  • A. It is a simple circuit
  • B. This makes the operation of appliances independent with each other
  • C. This results in reduced power consumption
  • D. All of the above

58. Which of the following does not affect resistance?

  • A. Resistivity
  • B. Cross-sectional area
  • C. Mass
  • D. Length

59. Which of the following is not considered a physical factor affecting resistance?

  • A. Length
  • B. Material type
  • C. Temperature
  • D. Cross-sectional

60. A 0.09 microfarad capacitor is charged to 220 volts. How long in milliseconds will it discharged resistor has a resistance of 20,000 ohms?

  • A. 1.5
  • B. 2.5
  • C. 1.25
  • D. 0.5

61. A trigger circuit consisting of a capacitor of 0.01 μF is connected in series with a resistor. If the circuit requires 100 Vdc to operate, determine the value of the resistor when time constant is 0.009s.

  • A. 900 Ω
  • B. 900 kΩ
  • C. 900 MΩ
  • D. 900 GΩ

62. The graph between an alternating quantity and time is called

  • A. Sine wave
  • B. Curve
  • C. Waveform
  • D. A plot

63. Which of the following is the most popular waveform?

  • A. Sinusoidal
  • B. Square wave
  • C. Triangular
  • D. Sawtooth

64. Which of the following does not refer to electrical energy?

  • A. Volt-ampere
  • B. Joule
  • C. Watt-second
  • D. Volt-coulomb

65. What is the resonant frequency of a circuit when L of 25 microhenrys and C of 10 picofarads are in parallel?

  • A. 10.1 kHz
  • B. 10.1 MHz
  • C. 101 MHz
  • D. 101 kHz

66. And ideal current source has an internal conductance of _____ siemen(s)

  • A. Infinite
  • B. One
  • C. Zero
  • D. One million

67. A capacitance of 6 µµF means

  • A. 6 pF
  • B. 6 nF
  • C. 6 fF
  • D. 6 aF

68. The voltage cannot be exactly in phase with the current in a circuit that contains

  • A. Only capacitance
  • B. Only resistance
  • C. Inductance and capacitance
  • D. Inductance, capacitance and resistance

69. The charge in the capacitor is stored at the

  • A. Terminals
  • B. Plates
  • C. Dielectric
  • D. Air

70. The reactance curve is a plot of frequency versus _____ for a series RLC circuit

  • A. Current
  • B. Voltage
  • C. Gain
  • D. Impedance

71. For a series circuit, the higher the quality factor

  • A. The greater the bandwidth
  • B. The narrower the passband
  • C. The broader the resonance curve
  • D. The wider the passband

72. “Any resistance R in a branch of a network in which a current I is flowing can be replaced by a voltage equal to IR”. This states

  • A. Compensation theorem
  • B. Reciprocity theorem
  • C. Millman’s theorem
  • D. Superposition theorem

73. The internal resistance of an ideal current source is

  • A. Infinite
  • B. Zero
  • C. Equal to the load resistance
  • D. To be determined

74. If three 100-pF capacitors are connected in series, then the total capacitance is

  • A. 300 pF
  • B. 100 pF
  • C. 50 pF
  • D. 33.3 pF

75. An inductance of 1 mH is

  • A. 0.001 H
  • B. 0.01 H
  • C. 0.0001 H
  • D. 0.10 H

76. A capacitor is basically constructed of

  • A. Two conductors separated by a dielectric
  • B. Two dielectric separated by a conductor
  • C. Conductors and dielectric
  • D. Conductors and semiconductors

77. In an inductive coil, the rate of rise of current is maximum

  • A. Near the final maximum value of current
  • B. At mid-value of current
  • C. At half-power points
  • D. After one time constant

78. Two complex numbers or phasors are said to be conjugate if they

  • A. Differ only in the algebraic sign of their quadratic components
  • B. Differ only in the algebraic sign of their real components
  • C. Are equal in their real and quadrature components including algebraic signs
  • D. Are equal in their real components but differ in their quadrature components including algebraic signs.

79. In an ac circuit with a resistive branch and an inductive branch in parallel, the

  • A. Voltage across the inductance leads the voltage across the resistance by 90°
  • B. Resistive branch current is 90° out of phase with the inductive branch current
  • C. Resistive and inductive branch currents have the same phase
  • D. Resistive and inductive branch currents are 180° out-of-phase

80. In an ac circuit with XL and R in series, the

  • A. Voltages across R and XL are in phase
  • B. Voltage across R lags the voltage across XL by 90°
  • C. Voltages across R and XL are 180° out-of-phase
  • D. Voltage across R leads the voltage across XL by 90°

81. Leakage resistance in a capacitor results into

  • A. Internal heating
  • B. Internal bleeding
  • C. Shorter useful life
  • D. Short-circuiting

82. Voltage resonance means

  • A. Series resonance
  • B. Parallel resonance
  • C. Current magnification
  • D. Gain magnification

83. The unit of elastance is

  • A. Farad
  • B. Daraf
  • C. Siemen
  • D. Henry

84. The farad is not equivalent to which of the following combination of units

  • A. CV­2
  • B. C2/J
  • C. C/V
  • D. J/V2

85. Which component opposes voltage change?

  • A. Resistor
  • B. Inductor
  • C. Capacitor
  • D. Transistor

86. What is the peak factor for alternating current or voltage varying sinusiodally?

  • A. 1.4142
  • B. 0.707
  • C. 0.636
  • D. 1.11

87. Which of the following is not a factor affecting dielectric strength?

  • A. Mass
  • B. Moisture content
  • C. Temperature
  • D. Thickness

88. The superposition theorem is used when the circuit contains

  • A. Reactive elements
  • B. Active elements
  • C. Number of voltage sources
  • D. Single voltage source

89. What refers to such work at very low temperatures, near absolute zero?

  • A. Cryogenics
  • B. Superconductivity
  • C. Subsonic
  • D. Thermionic

90. A factor that states how much the resistance changes for a change in temperature?

  • A. Resistivity
  • B. Specific resistance
  • C. Coefficient of temperature change
  • D. Temperature coefficient of resistance

91. An alloy composed of 84 % copper, 12 % manganese and 4 % nickel.

  • A. Manganin
  • B. Constantan
  • C. Nichrome
  • D. German silver wire

92. A law which states that when a constant electromotive force is applied to a circuit consisting of a resistor and capacitor connected in series, the time taken for the potential on the plates of the capacitor to rise to any given fraction of its final value depends only on the product of capacitance and resistance.

  • A. Child’s law
  • B. CR law
  • C. Coulomb’s law
  • D. Debye T3 law

93. At parallel resonance, the currents flowing through L and C are

  • A. Infinite
  • B. Zero
  • C. Unequal
  • D. Equal

94. In a rectangular wave, the peak factor is

  • A. 1.16
  • B. 1.73
  • C. 1.11
  • D. 1.0

95. In an RL series circuit,

  • A. Current lags voltage by less than 90˚
  • B. Current lags voltage by 180˚
  • C. Current lags voltage by 90˚
  • D. Current leads voltage by 90˚

96. In a pure capacitance,

  • A. Current leads voltage by 90˚
  • B. Current leads voltage by 180˚
  • C. Current lags voltage by 90˚
  • D. Current lags voltage by 180˚

97. The ohmic value of a resistor with negative temperature coefficient

  • A. Increases with increasing temperature
  • B. Increase with decreasing temperature
  • C. Stays unchanged with temperature change
  • D. Stays unaffected even with increasing temperature

98. Which of the statements below is not true?

  • A. Current source is an active element
  • B. Resistor is a linear element
  • C. Voltage source is a passive element
  • D. Diode is a non-linear element

99. Which of the following elements is active?

  • A. Resistor
  • B. Inductor
  • C. Capacitor
  • D. Ideal voltage source

100. What is the complex impedance of a circuit with an absolute resistance of 300 Ω?

  • A. 0 + j 300 Ω
  • B. 300 + j 90 Ω
  • C. 0 – j 300 Ω
  • D. 300 + j 0 Ω

NOTE:

For any Questions, Clarifications and any violent Reactions use the comment section below. I'll be much willing to assist you.
credit: ©2013 www.FroydWess.com
